The True High-End Pillow Packaging Solution
TPBMA-SS101D3SV
Top-Feed Pillow Packaging Machine (Box Motion Cutter, 3-Axis Servo Control & Stainless Steel Construction)
TPBMA-SS101D3SV is a top-feed pillow pack machine built for the bakery, confectionery, food processing, pharmaceutical, and consumer goods sectors. Engineered with a full stainless steel 304 frame, this model emphasizes hygiene and durability, offering a sanitary and application-specific solution for industries where cleanliness is critical.
Advanced technology at its core!
Box Motion with Intelligent Servo System!
Box Motion Mechanism
3-Axis Servo System for Full Automation
Conventional pillow pack machines rely on manual adjustments for the feeder, center seal, and end seal—resulting in time-consuming setup, frequent errors, and significant film waste.
In contrast, TEAMPACK’s advanced 3-axis servo control system automatically synchronizes all motion axes, enabling real-time product and film alignment for faster setup, higher accuracy, and reduced material loss.
Everything from startup to fine-tuned 3-axis control
Zero Mmanual Intervention Needed.
One touch is all it takes to control machine.
TEAMPACK’s pillow packaging machine integrates advanced hardware and software to deliver real-time, high-precision control. It rapidly converts sensor input and film measurements into actionable data, enabling seamless synchronization across all components. Digital signals from each sensor and line are processed through correction algorithms and feedback loops, ensuring accurate monitoring and responsive control of film length, sealing, and cutting operations — even in variable production environments.
Intuitive Control Box
The control box is designed for centralized, user-friendly operation. Featuring a large touchscreen, temperature control panel, and action switches, the interface allows operators to monitor all processes in real time with clarity and ease. The power switch has a clearly defined On/Off display with indicator lights, ensuring straightforward and safe operation.
– Operates on 220V single-phase power
– Maximum power consumption: approximately 4kW
Powered by LS Industrial Systems PLC
The TEAMPACK pillow packaging machine offers fully customizable control of all machine operations to suit on-site production requirements. The PLC system enables seamless integration with peripheral devices and interlocks. Digital signals from each sensor and operational unit are processed in real time, allowing the high-performance CPU and central controller to execute independent commands and monitor all machine functions with ultra-fast, high-precision responsiveness.
Panasonic Servo Driver
– Control Modes: Position, speed, torque, and full-closed loop control
– Power Supply: Supports 200V single- and three-phase input
– Input Types: Analog and pulse train compatible
– Communication: Modbus via RS485/RS232 for system integration
– Bandwidth: 3.2 kHz for fast, precise response
Electronic I-Mark Positioning
Conventional machines require manual adjustment of three axes to align the I-Mark and product position, often resulting in time-consuming setup and excess film waste. The TPBMA-SS101D3SV allows operators to simply input the desired value—automatically adjusting the position for immediate and precise cutting, with no manual intervention or film loss.
DOMINO Thermal Transfer Printer
– 7” touchscreen for easy message editing
– 300 dpi high-resolution printing
– Speed: up to 600 mm/s (intermittent), 750 mm/s (continuous)
– Fully electric — no compressed air required
*This unit is optional.
*Specifications may vary depending on production conditions.
For precise placement
Top-Feed is The Answer.
Under-product fin seal.
With the film positioned on top, operators can adjust it easily without bending. The open-frame design enables direct visual alignment of the I-Mark during film movement. A secure film bracket and fine-tuning handle allow quick and simple film adjustments even during production.
Product Infeed
Finished Package
Hygienic & customizable
Custom-Built Feed Conveyor.
Safe and hygienic product feeding conveyor.
The feed conveyor, responsible for transporting products to the packaging section, uses POE (Polyolefin Elastomer) attachments where items are placed, while the frame is constructed from hygienic stainless steel 304. TEAMPACK offers fully customizable conveyor configurations to suit different product shapes and packaging needs.
POE Material
POE (Polyolefin Elastomer) is a high-performance thermoplastic known for its dimensional stability and excellent resistance to deformation. As an engineering plastic, it offers strong chemical resistance and corrosion protection across various environments. Its outstanding insulating properties also make it resistant to static electricity, creating a stable and hygienic environment for safely transferring food, pharmaceutical, and consumer goods through the feed conveyor to the packaging section.
Sub Controller
The feeder conveyor is equipped with run, stop, and emergency stop switches, allowing operators to control the main pillow packaging machine directly from the conveyor. This enables safe and efficient operation without having to move to the main control panel, even while feeding products into the system.
Adjustment Handle
The feeder conveyor is equipped with a side-mounted adjustment handle that allows operators to widen or narrow the side guides. This design enables easy packaging of products in various sizes.
PE Material
Polyethylene (PE) is a thermoplastic resin with high impact strength at low temperatures. Its low moisture absorption, excellent chemical resistance, and corrosion resistance make it ideal for dry ice packaging. TEAMPACK offers custom-built conveyors using PE material specifically designed for dry ice handling environments.
Fresh Food Packaging
TEAMPACK offers conveyor systems specialized for packaging fresh products such as vegetables, fruits, baked goods, and pharmaceuticals. These systems prioritize temperature, humidity, and hygiene control, using carefully selected materials to meet food safety standards. Unlike conventional industrial conveyors, they are engineered with features that prevent contamination and ensure compliance with strict sanitary requirements.
Tailored Engineering
TEAMPACK offers both belt-type and rod-type feeder conveyors, custom-built to meet the unique needs of each production environment. By integrating various transfer systems, we optimize packaging lines for specific industries and product types. Through detailed customized design, TEAMPACK ensures seamless compatibility with existing automation equipment and machinery—delivering solutions engineered exclusively for each customer.
Independent temperature control
for Sealing and Cutting!
Digital temperature controller
The system features a digital temperature controller that allows users to set and maintain optimal temperatures in real time, ensuring high-quality film sealing. Temperatures for the sealing roller and cutting blade can be adjusted independently, based on the specific film and product being used. With simple up/down controls, each zone can be precisely set, and the controller maintains the target temperature consistently. Dedicated ON/OFF switches for each heater allow independent operation of the sealing and cutting units as needed.
Main control box
(temperature control section)
Center sealer
(sealer temperature setting)
Cutter sealer
(cutter temperature setting)
Operator protection comes first!
Safety-First Design.
PNE System
Automatic separation of sealing rollers & cylinder motion
Center Sealer Guide
Door-type structure to block external exposure to sealing heat
Acrylic Safety Frame
Transparent acrylic cover for clear visibility and operator protection
Indicator Lights
Clearly displays machine status: running, standby, or stop
SUS-304
Stainless Steel 304 Construction
Acrylic Shield
High-Visibility Acrylic Safety Shield
Acrylic offers excellent visibility with a light transmittance of approximately 92%, allowing operators to clearly monitor machine operation. Its low thermal conductivity provides effective heat insulation around high-temperature cutter-sealer areas. Despite being lightweight, acrylic is highly impact-resistant, dimensionally stable, and resistant to UV exposure and chemicals—ensuring long-term durability without yellowing or degradation.
Cutter Types
① Rotary Cutter: A continuously rotating blade system ideal for high-speed packaging of small, uniform products. (Recommended for: snacks, chocolates, face masks, medical products)
② Cylinder Cutter: A vertical cutting mechanism that delivers exceptionally tight and precise seals between the product and film. (Recommended for: frozen foods, general consumer goods)
③ Box Motion Cutter: Ideal for tall or irregular-sized products, offering stable speed and superior seal quality. (Recommended for: bread, books, panels)
